Specifications

Make

YLM

Description

The machine is equipped with a powerful functioning CNC controller. The controller employs a windows operation system in combination with the use of Ying Han self-developed CNC control software. Outstanding features include easy generation of bending parameters, 3D workpiece simulation function and single step operational simulation function, etc. These provide users with safe, easy and humanized control features.

Fully electric CNC pipe bender, All Electric Multi Stack CNC tube Bending machine

SPECIFICATION
Model CNC101MS-AE
Specification 101
Max. Tube O.D. Bending Capacity (mm) ? 100
Max. Tube Wall Thickness (mm) 4
Material MILD STEEL
CLR 250
Max. Bending Radius Difference (mm) 100
Max. Bending Angle (°) 190
Mandrel Working Distance (mm) 4000

Manufacture Speed
Tube Feeding Speed (mm/sec) 653
Tube Rotation Speed (°/sec) 348
Tube Bending Speed (°/sec) 32.1

Repeatability
Tube Feeding Precision (mm)
Tube Rotation Precision (°) ± 0.1
Tube Bending Precision (°) ± 0.1

Overall Weight (kg) 9620
Operating Height (mm) 1289
Machine Length (mm) 8094
Machine Width (mm) 2132
Machine Height (mm) 2071
