HEMS – Automatic Digital Tester HE-ADCT
Specifications
| Make | HEMS |
|---|
Description
The HE-ADCT testing machines are Automated digital cylinder testers.
You can wash the cylinders with clean oil and have the possibility to control the oil contamination level in compliance with ISO4406.
These Machines also have semi-automatic and manual modes.
Benefits
- Safe operation with fully enclosed design
- Accurate, repeatable test results
- Full traceability with digital test reports
- Reduced setup time and improved workflow efficiency
Key Features
- Automated hydraulic cylinder testing and flushing
- Integrated hydraulic power pack and large-capacity oil tank
- Built-in electrical board and instrumentation
- Continuous contamination monitoring during flushing
HE-ADCT-01
- All data validation or not validation are listed on a report, including the lot management
- USB interface for program backup to unload the test reports
- Contamination level is detected in real time / Contamination sensor PARKER ICount PD
- Complete safety closure via sliding tunnels
- Regular internal cleaning of the tank, eliminating the residues of contaminated material
- A heat exchanger to always keep the oil inside the tank cool
HE-ADCT-02
- All data validation or not validation are listed on a report, including the lot management
- USB interface for program backup to unload the test reports
- Controlled and reported flushing
- Pressure loss record in both stations
- Minimum sliding pressure record with oil non-energised seal
- Internal seal leak test
- Selectable long cycles
- Monitoring the temperature in the tank
- Contamination level is detected in real time / Contamination sensor PARKER ICount PD
AUTOMATIC DIGITAL CYLINDER TESTER Specifications
| Model | HE-ADCT-01 | HE-ADCT-02 |
|---|---|---|
| Tank Capacity | 400 litre | 650 litre |
| Max Testing Pressure | 450 bar | 415 bar |
| Cylinder Specification | 5000 mm extended length, 500 mm diameter | 10,000 mm extended length, 600 mm diameter |
| Weight | 1,200 kg (empty) | 2,000 kg (empty) |
| Max Cylinder Weight | 600 kg | 15 q (OCR unclear) |
| Pneumatic Feeding System Pressure | 6 / 9 bar | 8 / 10 bar |
| Internal Tank Capacity | 200 litres | 500 litres |
| Max Fluid Temperature | 50 degrees | 50 degrees |
This ISO 1000:2020-compliant automated cylinder tester is designed for safe, accurate hydraulic cylinder testing and flushing.
