WAUSEON – 1005HY – 5-hit Hydraulic End Forming Machine

Specifications

Description

WAUSEON – 1005HY – 5-hit Hydraulic End Forming Machine

1000 Series Hydraulic Five Stroke End Former Machine for most end forms up to 1” (26mm) diameter tube*

This 5-hit Hydraulic End Forming Machine (1005HY) has 6.5 tons of ram force, 9 tons of tube clamp force, and is capable of handling several unique applications.

New to this machine is an increased ram velocity of 11″ per second, compared to the previous 8.5″ per second, which provides users with a cycle rate improvement. With the addition of two ram strokes, this 5-hit machine provides more versatility and flexibility than our previous 1003HY model.

*Maximum tube diameter is dependent upon end form type, and tubing material type, grade, and wall thickness.

FEATURES & BENEFITS

Part Builder
• Capable of saving multiple part setup parameters
• When saved parts are selected, the number of hits and lubrication points (if applicable) are recalled
• Improve setup consistency, save time, and reduce the occurrence of setup errors

Programmable Retract Stroke Control
• Results in increased part output

Variable Frequency Drive Controlled Hydraulic Unit
• Less power consumption
• Quieter operation

Ergonomic Frame Design
• Ideal for a narrower cell footprint
• Easier access for tooling change-over and maintenance
• Light bar illuminates workspace
