Description

The instrument is able to determine the radius of a curve extremely quickly, it can be used indifferently both on the outside and on the inside of the curved profile.

By simply placing the gauge on the profile whose radius is to be determined, the instrument detects a measurement that, when searched for on the kit, immediately signals the radius. In this way, the operator working on a bending machine can easily control the curve up to the desired bending radius.

ANALOG meter of the bending radius.
Capability to measure inside and outside radius (convex and concave
curves).
Range of measured radii: 250 – 700.000 mm.
Supplied complete with machined bar for zero setting.
The radius is provided through a decoding chart
